Basic Info.
Hardness
20 ~90 Shore a
Transport Package
Plastic Bag & Carton Box
Specification
400x300x300mm
Trademark
Customization
Origin
Shenzhen China
HS Code
4016999090
Production Capacity
1000000PCS/Year
Product Description
Car Industry
LTR is an expert in manufacturing all kinds of components for the automotive and motorcycle industry. We are IATF16949:2016 certified in order to fully satisfy the requirements of this industry.
Our production includes O rings, gaskets, seals, grommets, bellows, shock absorbers, dampers, cushions, sleeves, isolators, couplings, bushings, boots, covers, bumpers, pipes, hoses, tubes and many other pieces which are mainly manufactured in ACM, AEM, BR, CR, ECO, EPDM, FKM, FVMQ, HNBR, NBR, NR, SBR, SIR to meet the physical properties specified by ASTM D2000 and SAE J200 documents.
Products above are only examples to show Shun Tai Rubber's core competences. All our rubber components are customised and made to order only. No standard product or catalogue is available.
Technical data
Compound: NBR 55 Colour:Black | ||||||||||||||||||
Base Polymer: NBR Specification: | ||||||||||||||||||
MAIN SPECIFICATION | MEASURE UNITS | REQUIRED VALUE | TESTED VALUE | TEST METHOD | ||||||||||||||
HARDNESS | Sh-A | 55±5° | ASTM D2240 | |||||||||||||||
SPECIFIC GRAVITY | g/mm^3 | \ | 1.189 | ISO2781 | ||||||||||||||
TENSILE STRENGTH | Mpa | \ | 15.56 | ISO37 | ||||||||||||||
ELONGATION | % | \ | 787.97 | ISO37 | ||||||||||||||
Tear Strength | kg/cm | \ | 48.18 | ISO34 | ||||||||||||||
Compression set,max | % | \ | 24.49 | ISO0815 24HX150°C | ||||||||||||||
SPECIFICATION CHANGE | ||||||||||||||||||
TEST MEANS | TIME h | TEMP ºC | HARDNESS | TENSILE STRENGTH | ELONG.AT BREAK | VOLUME | WEIGHT | |||||||||||
ISO0188 | 72 | 225 | +2 | -2.86 | -5.25 | required test | required test | |||||||||||
△ SHORE A | % | % | △% | △% | ||||||||||||||
