Basic Info.
Model NO.
600PS-150050R-12-STA
Maximum Load
430kg
Thickness
50mm
Cast Iron
Rubber on Cast Iron
Cheaper Caster
V-Groove Caster
Polyurethane Caster
Polypropylene Caster
Phenolic Caster
Mold on Rubber Caster
Elastic Rubber Caster
Mold on Polyurethane Casters
Round Tread PU Caster
Blue Elastic Rubber Caster
Thermoplastic Rubber Caster
TPU Caster
Transport Package
Carton Box
Specification
SGS
Trademark
WANDA
Origin
Jiangsu, China
HS Code
87169000
Production Capacity
1200000/Year
Product Description
Introduction:
Mold-on rubber casters have soft rubber tires molded on iron centers. soft rubber provides more desirable operating characteristics than any other wheel material. it is quiet, absorbs shock (prolonging equipment, life and protecting cargo), can roll over small objects, protects costly floor surfaces, and minimizes vibration. straight roller bearing with drilled hardened steel spanner bushing. for customization & special application options. please consult Wanda Casters.
60* Series Caster Mounting
Mounting Plate and Swivel Cross Section
Wanda's medium duty casters are feature a top plate and yoke of zinc-plated 0.23"(5.75mm) cold formed steel plate for high quality appearance and long life. Swivel sections feature double ball bearing raceways with axles at 1/2"in diameter.
Mold-on rubber casters have soft rubber tires molded on iron centers. soft rubber provides more desirable operating characteristics than any other wheel material. it is quiet, absorbs shock (prolonging equipment, life and protecting cargo), can roll over small objects, protects costly floor surfaces, and minimizes vibration. straight roller bearing with drilled hardened steel spanner bushing. for customization & special application options. please consult Wanda Casters.
| SPEC (inch) | Capacity Each (kg) | Wheel Dia D(mm) | Tread Width W(mm) | Wheel Bearing Type | Swivel Radius E(mm) | Overall Height H(mm) | Rubber Casters with lron Center Model No | |||||
| Rigid Casters | Swivel Casters | |||||||||||
| 4"x2" | 200 | 100 | 50 | Roller | 31 | 141 | 600PF-100050R-12 | 600PS-100050R-12 | ||||
| 5"x2" | 250 | 125 | 50 | Roller | 41 | 163 | 600PF-125050R-12 | 600PS-125050R-12 | ||||
| 6"x2" | 280 | 150 | 50 | Roller | 44 | 189 | 600PF-150050R-12 | 600PS-150050R-12 | ||||
| 8"x2" | 300 | 200 | 50 | Roller | 44 | 239 | 600PF-200050R-12 | 600PS-200050R-12 | ||||
| 10"x2" | 300 | 250 | 50 | Roller | 57 | 293 | 600PF-250050R-12 | 600PS-250050R-12 | ||||
60* Series Caster Mounting
Mounting Plate and Swivel Cross Section
Wanda's medium duty casters are feature a top plate and yoke of zinc-plated 0.23"(5.75mm) cold formed steel plate for high quality appearance and long life. Swivel sections feature double ball bearing raceways with axles at 1/2"in diameter.
