- Overview
- Detailed Photos
- Product Parameters
Basic Info.
Model NO.
I016-XXXF/S
Maximum Load
3000kg
Specification
6/8 Inch, Leveling Caster
Diameter
40/50/62/75/90 mm
Thickness
20/25/32/55mm
Color
White/Customized
Sample
Available
Customization
Available
Application
Trolley/Industry
Service
Standard Export Package
Transport Package
Carton
Trademark
WBD
Origin
Guangdong
HS Code
8716900000
Production Capacity
36500000PCS/Year
Product Description
WBD Caster Manufacturer 20+ years:
WBD High-Adjustability Extended-Stem Leveling Castor Corrosion-Resistant Heavy Duty Threaded stem Machine Retractable Casters with Ivory Hue Powder Coat Paint
| Size | Wheel diameter | Load capacity | Top-Plate size | Bolt hole spacing | Overall height |
| 1.5inch | 40x20mm | 50kg | 55x55x3mm | 42x42mm | 75±8mm |
| 2inch | 50x25mm | 250kg | 73x73x5mm | 58x58mm | 85±10mm |
| 2.5inch | 62x31mm | 500kg | 90x90x5mm | 70x70mm | 110±12mm |
| 3inch | 75x32mm | 750kg | 95x95x5mm | 70x70mm | 120±12mm |
| 3inch | 75x32mm | 1000kg | 95x95x6mm | 70x70mm | 120±12mm |
| 3.5inch | 90x55mm | 1500kg | 100x100x6mm | 70x70mm | 132±15mm |
Characteristics of different material casters
1. PU casters: Whether the casters work indoors or outdoors, they can meet your requirements.
2. TRP casters: They can be used in the situations that require less noise and work quietly, like working in hotels, on medical equipment, on floors, on wooden floors, on tile floors ....
3. Nylon casters and iron casters: The casters are suitable for the places where the ground is uneven or where there are iron scraps on the ground.
4. Rubber casters: The casters are inappropriate under the condition of acid, grease and chemicals.
5. Pneumatic casters: The casters are suitable for light load and the uneven roads .
2. TRP casters: They can be used in the situations that require less noise and work quietly, like working in hotels, on medical equipment, on floors, on wooden floors, on tile floors ....
3. Nylon casters and iron casters: The casters are suitable for the places where the ground is uneven or where there are iron scraps on the ground.
4. Rubber casters: The casters are inappropriate under the condition of acid, grease and chemicals.
5. Pneumatic casters: The casters are suitable for light load and the uneven roads .
In order to meet the market demands, we always keep paying attention to improving and developing our products and ourselves. Currently we offer more than 2000 different kinds of high quality casters combinations for almost every applications such as: industrial machine, medical facility, furniture, trolley, shopping cart, hand pallet, scaffolding, shelf and so on.
